Mimosa C6x Lite Edition (LE)

Overview: The Mimosa C6x Lite Edition (LE) is a radio device operating in the 6 GHz frequency band with modular antenna options for flexible installation. It supports high speeds in both point-to-point (PTP) and point-to-multipoint (PTMP) connections and features a rugged design for outdoor use. Its IP67-rated durable enclosure ensures reliable performance in harsh environments. The device operates within the 5150–7125 MHz frequency range and is powered by passive PoE. Key Features: Modular N5-X twist-on antenna support (12,16,20,25,30 dBi) for flexible installation. Maximum data rate of 1.0 Gbps in PTP mode and 750 Mbps in PTMP mode. IP67-rated rugged outdoor enclosure. Operates in the 5150–7125 MHz frequency range (country restrictions apply). Powered by 24 V passive PoE (PoE injector not included). Lightweight and compact design. Technical Summary: Maximum Data Rate (PTP): 1.0 Gbps Maximum Data Rate (PTMP): 750 Mbps Frequency Range: 5150–7125 MHz Modulation and MIMO: 2x2, PTMP MU-MIMO, BPSK-1024QAM Bandwidth: 20/40/80 MHz Output Power: 24 dBm Receiver Sensitivity (MCS 0): -90 dBm (80 MHz), -93 dBm (40 MHz), -96 dBm (20 MHz) Power Consumption: 20 W Power Supply: Passive PoE, 24 V (PoE injector not included) Dimensions (HxWxD): 178 x 113 x 67 mm Weight: 0.7 kg Protection Class: IP67 Ethernet: 10/100/1000-BASE-T Operating Temperature: -40 to +55 °C Package Contents: C6x Lite Edition radio unit
